Overview
Essential details
Warranty:
- More than 5 years
After-sale Service:
- Online technical support
Size:
- 1220*2440
Project Solution Capability:
- graphic design, 3D model design, total solution for projects, Cross Categories Consolidation
Application:
- Exterior
Design Style:
- Chinese
Place of Origin:
- Shandong, China
Brand Name:
- Neitabond
Model Number:
- NT-8001
Usage:
- Outdoor
Function:
- Anti-Static, Antibacterial, Fireproof, Mould-Proof
Surface Treatment:
- Anodized, Brushed, Foil Decoration, Mirror, PE Coated, Printing, PVDF Coated
Width:
- 1220/1500
Length:
- 2440/3200/5000
Thickness:
- 4mm
Surface coating:
- PE/PVDF/FEVE/UV Printing
Core material:
- Non-Toxic Low Density Polyethylene
Color:
- Poplular Color or OEM
Delivery time:
- 15-20 days after the color confirmed
Certification:
- EU Protocol/Reach/RoHS/Aama 2605/ En13501-1/Soncap
Glossy:
- 20%-80%
Market:
- Europe, America, Australia, etc
Packaging & delivery
Selling Units:
Single item
Single package size:
13X19X3 cm
Single gross weight:
0.100 kg
Package Type:
1. In bulk, 3mm: 1700-2400 sheets, 4mm: 1300-1500 sheets. 2. In standard export wooden pallet, 3mm: 1600 sheets; 4mm: 1200 sheets. As your request...
Picture Example:
Lead time:
Quantity(square meters) 1 - 500 501 - 1000 >1000 Lead time (days) 10 15 To be negotiated
Product Description
| Brand Name | NEITABOND acp aluminium composite panels |
| Panel size | 1) Standard size :1220mmx2440mmx3mm/4mm Non-standard size: 1250x3200mm, 1550x5800mm 2) Accepted thickness:2-4mm(standard) 5mm 6mm(new and special) 3) Accepted width: 1000mm, 1220mm,1250mm, 1500mm,1550mm (non-standard width, but availble),etc 4) Accepted Length: According to buyer's requirements (Max:6000mm) 5) Skin aluminium thickness indoors: 0.15*0.15mm 0.18*0.18mm 0.20*0.20mm outdoors: 0.5*0.5mm 0.4*0.4mm 0.3*0.3mm 0.25*0.25mm 0.20*0.20mm 0.15*0.15mm |
| Materials | 1) Front: aluminium alloy sheet coated with PVDF or PE. 2) Core: nontoxic low density polyethylene(LDPE)/plastic fireproof materials(B1 OR A2). 3) Back: aluminium coated with polyester service coating or just mill finish. |
| Quality | 1)Under common temperatures and radiation, the surface is no color different. 2)Under natural climate, film coating will be no flake,no rubbles,no vestige and no pulverization. 3)Under common environment, no flake,no rubbles. 4)products with PVDF coating guarantee 15~20 years. 5)According to international test standard, all the tested items are satisfied with high-class. |
| Characteristics | 1)Light weight, the intensity is high, easy to maintain, cut bend, arch and install. The panel average weight is 3.5 - 5.5 kg/sqm. 2)Extremely good for the weathering resistance, acidity, alkaline resistance, thermal insulation, acoustic insulation and damping. 3)The surface is smooth and flat and easy to maintain., just use neutral cleaner and water can totally renew the panel. 4)The aluminium surface is tough, the core PE panel is flexible, therefore the panel has high impact resistance. |
| Application | 1)Constructional exterior curtain walls; 2)Decorative renovation for storey-added old buildings; 3) Indoors decoration for interior walls, ceilings, bathrooms, kitchens and balconies; 4)Advertisement board, display platforms and signboards; 5) Wallboard and ceilings for tunnels; 6) Raw materials in industrial purpose; 7)Materials used for vehicle and boat. |
| Certification | According to GB/17448-1999 standard and have passed ISO9001, ISO14001, SGS, CE, BV etc. |
Any color and patterns can be customized.
♦ color
| Regular solid plain color | bright silver, pure white, ivory white, silver grey, black, Chinese Red, Reddish red... |
| Glossy | glossy white, glossy red, glossy black, glossy blue... |
| Pearl | glossy pearl white, glossy pearl red, glossy pearl blue, glossy pearl black... |
| Wood | teak, walnut, maple, pine, China fir, wild cherry... |
| Marble | indian red, rosso lepanto, imperial red... |
| Brushed | silver brushed, golden brushed, black brushed, brass brushed... |
| Mirror | Golden mirror, silver mirror, blue mirror... |
